Slotting Slitting and Creasing Machine

Characteristics This machine can complete angle cutting slotting, rolling line scoring creasing, cutting procedure at one time. It is characterized in high efficiency, high speed and clean edges without flaking, etc. Drive gear adopts no clearance conjugation, which can reduce the gear adjustment error.Gear adopts centralized oil lubrication, which can reduce noise and prolong the life-span.Slot cutter head adopts four cutters synchronization which can save order exchange timePhase adjustment adopts 360 degrees electric planet gear which is fast and correct. (Option) Main Technical Parameter Dia. of cutter head Φ400mmΦ480mmModel VYQ2000VYQ2200VYQ2500VYQ-2000VYQ2200VYQ2500Board Area(Mm) 1200×20001200×22001200×25001450×20001450×22001450×2500Max Slot Deepness 300 mm350 mmMin.Slot Space 120 mm150 mmSlot Width 7 mmSlot Speed 0-70 Pic/Min
