Slitting and Creasing Machine

Characteristics Cutting and Creasing Machine is used to cut and creasing the corrugated paperboard. The working axis uses high quality seamless pipe, which is durable. This machine has three times creasing, molding after two times advance press. It is suitable for creasing of different kinds of corrugated paperboard. Main Technical Parameter Model VSC2000 VSC2200 VSC2400 VSC2600 VSC2800 Max paperboard width 1950 mm 2150 mm 2350 mm 2550 mm 2750 mm Max paperboard thickness 10 mm 10 mm 10 mm 10 mm 10 mm Max working speed 120 M/Min Overall size(mm) 2400×650×1050 2600×650×1050 2800×650×1050 3000×650×1050 3200×650×1050 Electric power 1.1 Kw 1.1 Kw 1.5 Kw 2.2 Kw 2.2 Kw Weight 900 Kg 1100 Kg 1500 Kg 1800 Kg 2000 Kg
